Airframe Interface Kit for 28V Certified Aircraft (BM-AIK2A)
Kit to adapt aviation-specific BatteryMINDers for use with FAA-certified aircraft. Compatible with original, and current CEC2 series BatteryMINDer chargers (8A or less*).
Key Features:
|
|
OVPD- Over Voltage Protection Device
This device is designed to “crowbar” the Circuit Breaker by applying a short circuit electronically and “pop” the current Alternator Field Circuit Breaker when voltage is over 16 Volts to protect all of your electronics in your vehicle. If you want an OV device that has a “test button mode” we also offer this model: OVPD-TM Over Voltage Protection Device With Test Mode
Stratus Battery Replacement Kit
BB-TH-U Thermal Battery Box “U” Case
Thermal battery box to protect from radiated or convection heat. This battery box is designed to be compatible with our existing “U” case battery models; ETX1600, ETX900-24, ETX680-24-VNT.
The EarthX thermal battery box is designed to protect the battery in engine compartment installations from periods of high temperature (up to 1 hour), such as after shutdown, and from radiant heat from hot surfaces like exhaust systems during and after flight. This stainless-steel box has a mirror finish to minimize the effect of radiant heat, and it has a high-performance insulating foam layer between the box and battery to reduce effect of convection heat. Weight is .68Kg or 1 Lb. 8oz.
All batteries have optimal temperature ranges for use in operation. The ETX-Hundred series is rated for 140 deg F (60 deg C) or less for optimal longevity and performance of the battery. Typical lead acid batteries are rated to 113 deg F or 45 deg C.
Airframe Interface Kit (BM-AIK10A)
Airframe Interface Kit (BM-AIK1)
BB-TH-CO Thermal Battery Box “C” Case
Thermal battery box to protect from radiated or convection heat. Compatible with our existing “C” case battery models; ETX680C.
The EarthX thermal battery box is designed to protect the battery in engine compartment installations from periods of high temperature (up to 1 hour), such as after shutdown, and from radiant heat from hot surfaces like exhaust systems during and after flight. This stainless-steel box has a mirror finish to minimize the effect of radiant heat, and it has a high-performance insulating foam layer between the box and battery to reduce effect of convection heat. This battery box was engineered to be strong enough to withstand 30 G of force yet only weighs .375Kg or 13.2oz.
All batteries have optimal temperature ranges for use in operation. The ETX-Hundred series is rated for 140 deg F ( 60 deg C) or less for optimal longevity and performance of the battery. Typical lead acid batteries are rated to 113 deg F or 45 deg C.
BB-TH Thermal Battery Box “E” Case
Thermal battery box to protect from radiated or convection heat. Fits the “E” case batteries including ETX680/ETX900/ETX900-VNT/ETX1200. Designed to protect the battery in engine compartment installations from periods of high temperature (up to 1 hour), such as after shutdown, and from radiant heat from hot surfaces like exhaust systems during and after flight. This stainless-steel box has a mirror finish to minimize the effect of radiant heat, and it has a high-performance insulating foam layer between the box and battery to reduce effect of convection heat. The hold-down tab comes with a mounting fixture that can hold a cooling air duct up to 1” in diameter. This battery box was engineered to be strong enough to withstand 30 G of force yet only weighs .49Kg or 1 Lb. 1.2oz.
All batteries have optimal temperature ranges for use in operation. The ETX-Hundred series is rated for 140°F ( 60ºC) or less for optimal longevity and performance of the battery. Typical lead acid batteries are rated to 113ºF or 45ºC.
Citabria ETX900-TSO-AC-KIT
Installation kit to be used with the ETX900-TSO battery. This kit DOES NOT include the battery, it is sold separately.
Select options
This product has multiple variants. The options may be chosen on the product page
Scout ETX900-TSO-AC-KIT
Installation kit to be used with the ETX900-TSO battery. This kit DOES NOT include the battery, it is sold separately.
Select options
This product has multiple variants. The options may be chosen on the product page
Decathlon ETX900-TSO-AC-KIT
Installation kit to be used with the ETX900-TSO battery. This kit DOES NOT include the battery, it is sold separately.
Select options
This product has multiple variants. The options may be chosen on the product page
