Electrical
AIS-360 ARINC BUFFER/HS to HS/LS to LS
The AIS 360 ARINC Buffer/Isolator (833610-02) has two ARINC 429 inputs and two output channels. Labels received on the ARINC 429 low speed input are sent out on the low speed output; and labels received on the ARINC 429 high speed input are sent out on the ARINC 429 high speed output. The AIS 360 digital platform will convert or combine almost any type of digital avionics signal.
Fuel Flow Transducer | 7-90 GPH, Hall Effect, Straight Pick-up
Fuel Flow Transducer | 7-90 GPH, Hall Effect, Right Angle Pick-up
SR 623 Switching Relay | Six Two-Pole Relays
Standard Multi-Circuit Toggle Switch | 6 pole, On-None-On + False
AIS 240B-35 Switching Module | 28VDC, For MARC 35 + False
The AIS240A-35 is a multi-purpose switching unit, consisting of six, four pole relays for a total of 24 poles of switching capabilities. The relays are arranged in a group of four (16 poles) and two single relays (4 poles each). The relays can be activated by either a ground or 28 Vdc, maximizing installation flexibility. The AIS240A-35 uses gold plated dry contacts that are sealed in nitrogen filled cases.The rugged construction makes them ideal switching units for both fixed wing and helicopter operations.
SR64-1 Switching Relay Module | MARC 70, 24 Pole
The SR 64 provides 24 poles of switching through six, hermetically sealed, bifurcated relays. The relays contacts are gold plated and have a 2 amp resistive load rating at 28 VDC. Coil current is 120 mA. K1, K2, K3 and K4 are switched simultaneously through coil pins, 71 and 72. K5 and K6 are independently switched through their coil pins.
SR 54 Switching Module | 20 Pole
The SR 54 switching relay provides 20 poles of switching through five hermetically sealed, bifurcated relays. The SR 54 has a built-in circuit that switches all relays to their de-energized condition whenever K6 is activated. This can be used for such applications as insuring LOC is presented on the HSI whenever a LOC signal is selected.
AIS 200B-35 20 Pole Switching Module
The AIS 200B-35 is a 20-pole, signal level, switching unit designed for use with NAV systems that share the aircrafts HSI/CDIs OBS functions. The contact switching rating is limited by the circuit board track current capacity to 1.0 amp. This unit has a revisionary relay which selects the LOC signal for display on the HSI/CDI whenever a LOC channel is selected in the NAV unit. This unit uses 10 relays in a series/parallel arrangement to provide the same 20 poles of switching. While model AIS 200B-35 is a direct fit and replacement for the AIS 200-35 and AIS 200A-35 models, installation of this AIS 200B-35 remains the same. Operates on 28 VDC.
