6430032-1 Emergency Battery Power Supply
$3,333.00
Benefits
- Provides reliable DC power for critical equipment and emergency lighting in the event of main aircraft power failure
- 6.2 VDC nominal, 7 amps maximum output power
- Utilizes Nickel Metal Hydride (NiMH) battery technology
- Can be fully recharged or maintain existing full charge via the aircraft’s primary power bus
- Direct replacement for Radiant RPS1-A / B; 2013-1A power supply and battery pack
- Direct replacement for Bruce Industries 100865; 2013-BR power supply and battery pack
- 4–6 years battery life expectancy
- 2-year on-wing capacity check with no removal required
- Designed and built in Wichita, Kansas USA
- Two-year limited warranty
- FAA TSO Certified
Specifications
Capacity
32 watt-hour
Input Voltage
16 – 32 VDC
Output Power
6.2 VDC nominal, 7 amps maximum
Run Time
153 minutes @ 2.0 amps
Technology
Nickel Metal Hydride (NiMH)
Weight
1.85 lbs. (0.84 kg)
Dimensions
10.8”L x 3.3”W x 2.0”H
(274mm x 84mm x 51mm)
Power Supply and Battery Pack Direct Replacement
Radiant RPS1-A / B; 2013-1A
Bruce Industries 100865; 2013-BR
Battery Life Expectancy
4 – 6 years
Protection
Short circuit, under temperature, over temperature, under-voltage, over-voltage, and EMI filtering
Mating Connector
C48-16R16-24S-100
MS24266R16B24SN
Case
Anodized aluminum
Certification
FAA TSO-C173a certified
DO-293A qualified
RTCA DO-160G qualified
| Weight | 0.1 lbs |
|---|---|
| Dimensions | 0.1 × 0.1 × 0.1 in |
| Brand | Mid-Continent Instruments and Avionics |
