ORION 500 SERIES POSITION / ANTI-COLLISION TAIL LIGHTS
Price range: $595.00 through $605.00
The Orion™ 500 Series products incorporate both the WHITE flashing Anti-Collision light, and the Tail Position light functions. State of the art LED circuitry is built in to eliminate the need for separate flasher boxes for operation. The footprint, and mounting, are identical to legacy Whelen products for ease of installation and retrofit. Fully FAA/TSO and STC approved.
TECH SPECS
- Drawing 71774
- Weight 0.28 lbs.
- Current Draw 14V / 28V 0.20 / 0.10 Amp (Position) 3.8 / 1.9 Amp (Anti-Collision) Average
- Lenses Clear Hardcoated Polycarbonate
| Model | Part # | Description | Approvals |
| OR5001V | 01-0771774V01 |
White Tail Position / Anti-Collision Light Assembly, 14 VDC
|
FAA TSO-C96a Class II / TSO-C30c Type III / STC |
| OR5002V | 01-0771774V02 |
White Tail Position / Anti-Collision Light Assembly, 28VDC
|
FAA TSO-C96a Class II / TSO-C30c Type III / STC |
DOCUMENTS
- STC ORION 500- SA800EA
- EASA STC – 10055068 Fixed Wing
- EASA STC – 10056206 Rotorcraft
- Brazlian STC – Formulario F 400 01G 0806731
- Install Guide: 14710 – Tail PTA Light 28V
- Install Guide: 14709- Tail PTA Light 14V
- Installation & Service Manual – Document #05131 Rev. E
CROSS REFERENCE
| Legacy Product Part Number | Legacy Part Model Number | Orion™ 500 Part Number | Orion™ 500 Model Number |
| 01-0770024-00 | A500AV14 | 01-0771774V01 | OR5001V |
| 01-0770024-01 | A500AV28 | 01-0771774V02 | OR5002V |
| 01-0770034-00 | A555AV14 | 01-0771774V01 | OR5001V |
| 01-0770034-01 | A555AV28 | 01-0771774V02 | OR5002V |
NOTE: Any highlighted RED ITEMS will require extra wiring for Anti-Collision function of the Orion™ series.
WARNING: These products may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
| Weight | .1 lbs |
|---|---|
| Dimensions | 10 × 8 × 6 in |
| Brand |
Whelen |
| Model |
OR5001V White Tail Position / Anti-Collision Light Assembly, 14 VDC ,OR5002V White Tail Position / Anti-Collision Light Assembly, 28VDC |
