Hand Crimp Tool | 24-30AWG Pin/Socket & SPOX, 20-28AWG KK Terminals
The 207129 series hand crimp tool provides a high quality connection between a terminal and a wire. The ratcheting mechanism ensures a secure crimp while reducing hand strain from manual crimping. For use with 1.57mm Pin and Socket Terminals 24-30 AWG, 2.50mm SPOX Terminals 24-30 AWG, 2.54mm KK Terminals 20-28 AWG.
A200-HMS – Slick/Unison Rotational Speed Sensor
The A200-HMS is an Hall Effect rotational speed sensor. It provides a speed accuracy of 1 RPM when used in conjunction with the TM200 instrument.
The output signal is a latched, pulse width modulated square wave output of 0V to a maximum of 30V, proportional to rotational speed.
Power requirements are 3.8V to 30V / 3mA.
Precision machined from 6061 T6 aircraft grade aluminum, this sensor is designed to thread into the vent hole of Slick/Unison unpressurized magnetos.
Supplied with a 48" color coded cable.
When installed in accordance with the approved instructions and as part of a qualified instrument system, this speed sensor is STC'd as a primary replacement.
