Category – Avionics – Electrical
VI-2µFA SureFly Ignition Interface
VI-2µFA SureFly Interface Works with SureFly SIM4P Connect to the RPM input channel using E.I.’s VI-2µFA Use with EDC-33 (MVP
AIR Traffic (AT‑2)
Dual Band ADS-B IN System with comprehensive interfaces and traffic warning functions.
Features
- Dual Link ADS-B In. Receives ADS-B, ADS-R, TIS-B and FIS-B data. Detects any kind of ADS-B traffic (also SIL=0 "no integrity" signals). Detects Mode-S Transponder signals from non-ADS-B traffic
- Detects threats and gives warnings of conflicting traffic. Trajectory-based warning engine for minimum nuisance alerts. Audio out for synthetic voice warnings on the intercom.
- Works with all systems on the market that are capable of displaying traffic, including flight decks, navigators apps, and dedicated displays. Features eight independently configurable wireless and wirebound interfaces: RS-232, ARINC429, Wi-Fi®, Bluetooth®, Discrete I/O and Audio
Compatible with: Cockpit Displays (AIR Avionics ATD-57, ATD-80, ATD-11 and many more), Flight Decks (GARMIN® and Avidyne®, DYNON®, ADVANCED®, GRT® and many more), Portable Navigators (GARMIN®, Bendix King® and many more), Apps (e.g. ForeFlight® and many more).
ETZ5G
ETX12A
ETX36D
ETX900-VNT
StartStick 10Ah (10 amp)
Model Number: StartStick 10
Technical Description
AN2551 3-Pin Aircraft External Power Plug (904-342)
AN2551 3-Pin Aircraft External Power Plug
Designed to plug into standard AN2552 external power receptacle found on most General Aviation aircraft. Rugged polycarbonate shell, assembled with stainless steel hardware. Torch-soldered heavy-duty copper contacts with silver plating. Up to 0 AWG wire. 50% more power handling. Up to 1600A peak. Sometime referred to as a NATO or Cessna style plug.
Piper Aircraft Jumper Cable (802-690B)
Features
- Piper single-pin external power plug
- PVC-coated insulated copper jaw clamps
- 20 ft. 4AWG cable
Heavy-duty 500-amp/600 peak, 20 foot, 4-gauge, tangle-free rubber-coated cables. Terminated with PVC-coated insulated copper jaw clamps at one end and single-pin Piper aircraft external power plug.
ETX900-TSO-35-PA-KIT
STC installation kit to be used with the ETX900-TSO. Use for replacing a Concorde or Gill 35 Ah battery.
We are adding kits for many other make/models. Please check back regularly.
ETX-QCC2 24″ EarthX Quick Connect Cables
SPECIFICATIONS
- Max jump start amps: 400 amps
- Length: Battery “pigtail” cable = 24”/60 cm
- Jump pack adapter cable: 6.5”/16.5 cm
- 1/4″ / M6 ringlets
- Industry standard 2-pole SAE connector, with rubber sealing cap.
- Cable max. rating: 400 Amp
When not in use, keep rubber sealing cap closed on the SAE connector end.
You can then use this pigtail to charge your battery or for jump starting.
If the cables get hot, disconnect and allow them to cool down before use.
Caution: Never use the supplied battery chargers pigtail cables that comes with your charger for jump starting as they are not designed to carry this amount of amperage. Only use the EarthX quick connect (model #ETX-QCC2) cables to jump the battery.
ETX-JMP12/24 12V-24V Jump Pack (All-In-One)
This is a 12V/24V jump pack that can boost just about anything! Very compact and the entire kit is only 4 pounds. This jump pack uses the technology of lithium iron phosphate (LiFePo4) chemistry, not Lithium Cobalt (LiCoO2). LiFePo4 is the most powerful, safest and most robust of all the lithium chemistries, plus double the life span of lithium cobalt packs.
Examples of what it can jump start: automobiles, diesel trucks, motorcycles, boats, construction equipment, experimental and certified aircraft, tractors, snowmobiles, ATV/UTVs, riding lawnmowers, and so much more.
BB-TH-U Thermal Battery Box “U” Case
Thermal battery box to protect from radiated or convection heat. This battery box is designed to be compatible with our existing “U” case battery models; ETX1600, ETX900-24, ETX680-24-VNT.
The EarthX thermal battery box is designed to protect the battery in engine compartment installations from periods of high temperature (up to 1 hour), such as after shutdown, and from radiant heat from hot surfaces like exhaust systems during and after flight. This stainless-steel box has a mirror finish to minimize the effect of radiant heat, and it has a high-performance insulating foam layer between the box and battery to reduce effect of convection heat. Weight is .68Kg or 1 Lb. 8oz.
All batteries have optimal temperature ranges for use in operation. The ETX-Hundred series is rated for 140 deg F (60 deg C) or less for optimal longevity and performance of the battery. Typical lead acid batteries are rated to 113 deg F or 45 deg C.
BB-MU2 Light Weight Aluminum Battery Box
The light weight aluminum battery box is excellent to use with the EarthX lithium “E” case batteries for easy installation. Has a bolt-down tab for easy removal of the battery from the front or top, and is acrobat rated (even with PC680).
This battery box can be used with: ETX680, ETX900, ETX900-VNT, ETX1200, and Odyssey’s PC680
If you are using the battery box for the EarthX Lithium batteries, you will use a foam spacer on the left and right side of the battery for a snug fit. If you are using the battery box for the PC680, you will use the foam spacer on the backside at the bottom of the case to adjust for the tapering of the case for a snug fit.
This battery box was engineered to be strong enough to withstand 30 G of force for the EarthX Lithium Batteries or 6G of upward force and 9G of downward force with the PC680. It only weighs .23Kg or 8oz. This unique design allows for simple, easy installation with the dimensions: 7.1″ L x 3.1″ W x 6.5-6.6″ (adjustable height) or (180mm x 80mm 166-168mm).
What’s included:
- 1 x battery box
- 1 x top front removeable hold down tab
- 2 x screws for hold down
