B800 Yoke Mount Digital Clock for Beechcraft King Air | 5V NVIS Green A Lighting, Black Color
7270-5 Series Circuit Breaker | 10 Amp Rating, Bat Toggle
7270-5 Series Circuit Breaker | 15 Amp Rating, Bat Toggle
A200-TSO Oil Temperature Sensor
The A200-TSO is a monolithic temperature sensor with on-chip signal conditioning and an operating temperature of -50°C to 150°C. It has an accuracy of +/- 0.5°C over the full operating range.
The output voltage is proportional to the temperature x the supply voltage (ratiometric). The output swings from 0.25 V at −50°C to +4.75 V at +150°C using a single +5.0 V supply.
The temperature transfer function is:
VOUT = (V+/5 V) × [1.375 V +(22.5 mV/°C) × TA]
Power requirements (when used with any 200 Series instrument) are 5V / 1mA.
The sensor has a 5/8-18 threaded body and includes a copper crush washer.
Supplied with a 48" color coded cable.
When installed in accordance with the approved instructions and as part of a qualified instrument system, this temperature sensor is STC'd as a primary replacement.
400 Series Voltage & Amperage Meter | 2-1/4 Mount, 14V Orange Lighting
M475VA Voltage & Dual Amperage Meter | 2-1/4 Mount, 5V Orange Lighting | Remote Version
400 Series Voltage & Amperage Meter | 2-1/4 Mount, 28V Orange Lighting
Champion Aerospaceâ„¢ Turbine Engine Igniter, Silver, For Honeywell GTCP36-100 Series Aircraft Engine
CI 120-5 VOR GS POWER COMBINER/BNC Female Connector, 108-118 MHz and 329-335 MHz, 50 Ohms
The CI 120 series VOR/GS power combiners are either a two-input and one output, or two input and two output power combiner designed for the CI 120G/S blade set. It combines VOR/LOC and GS signals from individual blades and are typacally used with one or two coaxial cable runs to feed NAV1 or NAV2 receivers.
