6752-100 Series Circuit Breaker | 90 Amp Rating, Push Button
3TC2 Series Circuit Breaker | 35 Amp Rating
RAMI AV-535 Bent Whip Antenna | FM Extended Band
A200-TSA Outside Air Temperature Sensor
The A200-TSA is a monolithic temperature sensor with on-chip signal conditioning and an operating temperature of -50°C to 150°C. It has an accuracy of +/- 0.5°C over the full operating range.
The output voltage is proportional to the temperature x the supply voltage (ratiometric). The output swings from 0.25 V at −50°C to +4.75 V at +150°C using a single +5.0 V supply.
The temperature transfer function is:
VOUT = (V+/5 V) × [1.375 V +(22.5 mV/°C) × TA]
Power requirements are 5V / 1mA.
The sensor has a 5/16-24 threaded body and is supplied with two nylon mounting washers and a Nyloc fastening nut.
Supplied with a 48" color coded cable.
When installed in accordance with the approved instructions and as part of a qualified instrument system, this temperature sensor is STC'd as a primary replacement.
TC90 Controller with installation kit (dual upgrade)
Light Wedge Power Inverter | 24VDC–28VDC, 120V/400Hz Output
The 10-800 series power inverter is designed for powering up UMA EL instrument lighting bezels. This unit converts DC current to AC current uses two wires setup to deliver 120-volt/400Hz power. Up to 30 UMA light bezels maybe connected or three large EL lights in parallel to one another (Beechcraft Bonanza).
This 10-800 inverter operates on 24 VDC — 28 VDC.
Variable Intensity Lighting Controller
Variable Intensity Lighting Controller - REV 1 Instrument ONLY
NOTE: This item is only required for use on products purchased BEFORE 03-JAN-2013
ONLY USE THIS ITEM TO REPLACE AN EXISTING REV A UNIT IF IT HAS FAILED.
Products manufactured after this date have this unit INCLUDED and are connected to the panel lighting system or a separate potentiometer.
The A200-DDC Intensity Controller will support up to ten Rev 1 instruments in a single installation. It provides infinitely variable, uniform intensity control for all instruments.
These units are TSO qualified with all 200 Series instruments and is STC'd as a primary replacement instrument component under all flight conditions (day/night VFR and IFR).
M800 Series Digital Clock | 5V NVIS Green A Lighting, Black
7270-5 Series Circuit Breaker | 7.5 Amp Rating, Bat Toggle
RAMI AVT-4 Airborne Communications | VHF
The AVT-4 is a broad-band VHF communications antenna. It incorporates a low drag blade housing design for high strength and a radiating element encapsulated in rigid polyurethane foam. The housing is finished with a Skydrol resistant white polyurethane paint and comes with mounting hardware and neoprene mounting pad. The antenna is designed to operate at speeds up to 350 mph and altitudes of 50,000 ft. It has a drag force of 0.85 lb. @ 250 mph.
