Inline Attenuator | 20dB, BNC
$243.80
Part 500-3200 is a 20 dB attenuator for use with Artex ELT test sets. Attenuators maybe used to connect an ELT to an ELT test as necessary. This inline attenuator uses BNC type connectors.
Features
- 20 dB
- 1-Watt
- 50-Ohm
- BNC Male / Female
- VSWR: 1.05:1 (Typical)
- DC to 2.0 GHz (Usable to 4.0 GHz)
- Flatness: 0.10 dB (Typical To 2.0 GHz)
| Weight | 0.1 lbs |
|---|---|
| Dimensions | 10 × 8 × 6 in |
| Brand | ACR Artex |
