Features

• 150 VA continuous output
• 200 VA peak power for 5 minutes
• Lightweight, compact and portable
• Provides short circuit and overload protection and easy access to a user replaceable fuse
• 400 VA surge power

Specifications

Weight:
1.08 lb (490 g)

Dimensions:
6.06 x 2.87 x 1.77 in (155 x 75 x 40 mm)

Input Voltage:
22-30 VDC,
28 VDC, nominal

Input Current:
10A maximum at 200VA, 7.5A nominal

Standby Input Current:
0.20A

Output Voltage:
115 VAC

Output Frequency:
60 Hz

Output Waveform:
Modified Sine Wave

Output Power, Continuous:
150 VA

Output Power, Peak:
200 VA for 5 minutes

Output Power:
200 VA, surge

Efficiency:
90%

Battery Low Alarm:
22 VDC ±0.5 VDC

Battery Low Shutdown:
21 VDC  ±0.5 VDC

Thermal Protection:
176ºF (80ºC)

Overload Protection:
Yes

Short Circuit Protection:
Yes
