RAM® Twist-Lock™ Suction Cup Mount with Flat Panel Adapter
$55.99
The RAM-B-166-375U consists of a medium length B-size arm with our 3.3″ diameter suction cup base, and Track Ball™ Flat Panel Adapter.
Features
- 13″ x 8″ precision laser cut sun visor blocks unwanted glare; ideal for pilots
- Features a 50% dark grey tint
- Includes RAM® Composite Double Socket Swivel Arm and RAM® Twist-Lock™ Suction Cup
- Backed by a lifetime warranty*
Specifications
Hardware included:
Assembly Hardware
(1) #10-32 x 1.5″ Flat Weld Bolt
(1) #10-32 Nylock Nut
Suction size:
3.3″ Diameter
Socket to socket length:
3″
Ball size:
B Size (1″)
Weight capacity:
Standard Use: 2 lbs
Heavy-Duty Use: 1 lb
Materials:
Marine-grade aluminum
High strength composite
Packaging type:
Poly Bag
Weight:
0.61 lb
| Weight | .1 lbs |
|---|---|
| Dimensions | 10 × 8 × 6 in |
| Brand | RAM Mounts |
