SiteHawk General Purpose RF Test Kit | SK-6000-TC

Weight:
1.98 lb (0.9 kg)

Dimensions:
7.7 x 3.6 x 2.4 in (195 x 90 x 60 mm)

Frequency Range:
1 MHz to 6000 MHz

Frequency Resolution:
1 kHz

Output Power:
-10 dBm, typical

Trace Noise Magnitude (IFBW 1kHz):
0.05 dB rms

Measurement Speed:
1 ms/data point

Measurement Points:
51 to 3201

Measure Bandwidth:
100 Hz to 30 kHz

Operating Temperature:
14 °F to 131 °F (-10 °C to 55 °C)

Storage Temperature:
-40 °F to 176 °F (-40 °C to 80 °C)

Battery Charging Temperature:
32 °F to 95 °F (0 °C to 35 °C)

Temperature Stability:
0.01 dB/°F (0.02 dB/°C)

Return Loss Measurement Range:
0 dB to -60 dB

Resolution:
0.01 dB

VSWR Measurement Range:
1.0 to 65.0

Cable Loss Measurement Range:
0 dB to 30 dB

DTF Range:
0 to 5000 ft (0 to 1500 m)

Corrected Directivity:
> 38 dB

Maximum Input Voltage:
50 V

Immunity to Interfering Signals:
+13 dBm

Frequency Accuracy:
±2.5 ppm @25 °C

Reflect Amplitude Accuracy:
-10 dB to 0 dB:  ±0.6 dB
-20 dB to -10 dB:  ±0.8 dB
-35 dB to -20 dB:  ±3.0 dB

Connector:
USB Type-C, USB 3.0

Test Port Connector Impedance:
N Female, 50 ohms

Display:
5.5 in, 720p

Languages:
English, Chinese, Spanish

Battery Type:
Lithium-ion rechargeable

Battery Operating Time:
10 hours (typical)

Battery Charge Time:
5 hours (typical)

Storage Capacity:
Thousands of trace and setups

Recommended Calibration Interval:
3 years
