Insertion/Extraction Tool | 22 Gauge, Plastic Tips, Yellow & White
Two-Step Band Application Tool | 0.250 Wide, M81306/2-01A
HYDRAULIC CRIMP TOOL – HD51
DANIELS CRIMP TOOL/M22520/7-01. Dies sold separately
Qualified to MIL-DTL-22520/7, the DMC MH860 is a recent addition to the military specification. It was developed to meet the demonstrated need for supporting the majority of electrical systems with one versatile crimp tool frame. The MH860 accepts the entire middle wire range of 16 through 28 AWG, with positioners which adapt it to virtually all applications consistent with others in the MIL-DTL-22520 family.
AF8 Adjustable Indent Crimp Tool | M22520/1-01
The AF8 crimp tool is qualified to MIL-DTL-22520/1 and is compatible with the wire range of 12 through 26 AWG. With over a thousand available turret heads, the tool frame can be adapted to very specific military or proprietary contact/wire combinations. The AF8 provides an 8-impression crimp, assuring maximum tensile strength with almost every closed barrel contact. Tool requires a compatible turret head and positioner.
M22520/5-01 CRIMP TOOL
The DMC HX4 Crimp tool features a system of interchangeable dies which eliminate the need of separate fixed die crimp tools for each and every different application. Many maintenance and manufacturing concerns have standardized on this model, thus eliminating the cost associated with maintainaing and calibrating bulky inventories of single purpose tools.
