EDM-730 Options

EGT fast response grounded probe with Clamp (2 ¼ max OD), Ring Terminals (2)

CHT Military type Bayonet fast response grounded probe spring loaded with 3/8-24 thread.

CHT M-113-3/8 probe (JPI CHT to coexist with Factory bayonet probe or Heaters)

CHT gasket probe for under the spark plug 18 mm 14 mm 12 mm

TIT Probe, specify M-111T(Clamp) T-118 (1/8” NPT), M-111TT (7/16”-20) or T-114 (1/4” NPT)

OAT, Outside Air Temperature System

IAT/CDT Induction air, Compressor Temp, and Carb Carburetor Temp.

Oil Temperature 1/8 NPT thread PN 400505 Advisory

Oil Temperature 5/8-18 thread PN 400509 Primary

OIL pressure sensor to EDM-700/800 and 730 PN 306018 VDO

RPM std. sensor for Slick or Bendix Mag

Manifold pressure PN 604010 for EDM-800 and 730/830 series

Primary Series Fuel Pressure Non-Turbocharged

Primary Series Fuel Pressure, Turbocharged upper/lower deck pressure

Primary Series Manifold pressure, Oil Pressure

Fuel Flow option (730), Without transducer, Harness included

. Fuel Flow option (730), With FloScan transducer (201 or 231) Harness included

High flow transducer for some 9 cyl. ( 6 to 120 GPH ) TSO’d.

Real-Time Data Out: RTDO, provides telemetry data for UAV's, racers and other applications.

Carbon Monoxide Detector: by CO Guardian, Unit also provides Cabin Pressure (altitude) and Cabin Temperature.

Software upgrade all models
