SON-ALERT-SC648 AUDIO ALARM FOR MODELS 800, 803, 850 & 877
$56.62
The Sonalert is an audio alarm for Davtron Chronometers, compatible with models 800, 803, 850, and 877.
The Sonalert is an audio alarm for Davtron Chronometers, compatible with models 800, 803, 850, and 877.
Features
- Mode of Operation Continuous tone
- Frequency 2900 Hz ±500 Hz
- Voltage Rating 10-48 Vdc
- Loudness (Min. Voltage) 68 dB(A) min. @ 2 FT and 10 Vdc
- Loudness (Max Voltage) 80 dB(A) min. @ 2FT and 48 Vdc
Specifications
- Mode of Operation Continuous tone
- Frequency 2900 Hz ±500 Hz
- Current Draw 4 mA Max @ 10 Vdc
- Current Draw 18 mA Max @ 48 Vdc
- Weight (Typical) 1.5 oz (42 g)
- Housing 6/6 Nylon, Color Black
- Voltage Rating 10-48 Vdc
- Loudness (Min. Voltage) 68 dB(A) min. @ 2 FT and 10 Vdc
- Loudness (Max Voltage) 80 dB(A) min. @ 2FT and 48 Vdc
- Storage Temperature -40°C to +85°C
- Operating Temperature -30°C to +65°C
- Options contact factory (Mallory Sonalert Products Inc.)
| Weight | 0.1 lbs |
|---|---|
| Dimensions | 0.1 × 0.1 × 0.1 in |
| Brand | Davtron |
