Category – Instruments – Safety
M650
M650 FEATURES UNIT FOR TESTING BLIND ENCODERS ON TEST BENCH PRESSURE ALTITUDE AUTOMATIC DIMMING SUNLIGHT READABLE DISPLAY SPECIFICATIONS Pressure Altitude:
Select options
This product has multiple variants. The options may be chosen on the product page
Astro+
Your New Cockpit Companion Portable ADS-B Receiver The Astro+ combines a state-of-the-art aviation-grade AHRS technology, dual-band ADS-B Receiver, and an
Select options
This product has multiple variants. The options may be chosen on the product page
A200-PMP Manifold Pressure Sensor
The A200-PMP is a bulk micro-machined, absolute type pressure sensor for use in both harsh and benign media with superior accuracy over an operating temperature of -40°C to 105°C. It has superb accuracy of +/- 0.5% full scale.
It contains a custom ASIC which provides signal conditioning for calibration and temperature compensation at the point of measurement. Each sensor is traceable to NIST calibration standards.
Power requirements are 5V / 10mA. Signal output is linear and varies from 0.5V (0 PSI) to 4.5V (50 PSI). Overpressure burst rating is 300 PSI.
The sensor has a 1/8" NPT threaded port for connection to the manifold pressure line.
Supplied with a 36" color coded cable.
When installed in accordance with the approved instructions and as part of a qualified instrument system, this pressure sensor is STC'd as a primary replacement.
A200-PSF Fuel Pressure Sensor
The A200-PSF is a bulk micro-machined, gage type pressure sensor for use in both harsh and benign media with superior accuracy over an operating temperature of -40°C to 105°C. It has superb accuracy of +/- 0.5% full scale.
It contains a custom ASIC which provides signal conditioning for calibration and temperature compensation at the point of measurement. Each sensor is traceable to NIST calibration standards.
Power requirements are 5V / 10mA. Signal output is linear and varies from 0.5V (0 PSI) to 4.5V (100 PSI). Overpressure burst rating is 300 PSI.
The sensor has a 1/8" NPT threaded port for connection to the fuel pressure line.
Supplied with a 36" color coded cable.
When installed in accordance with the approved instructions and as part of a qualified instrument system, this pressure sensor is STC'd as a primary replacement.
PT-100GA – Pressure Transducer
Stratus ESG (Experimental)
PT-100GA – T Torque Pressure Transducer
S-50 External Shunt
BOM
It’s there when you need it A True Backup Solution The BOM will have your back during an instrument malfunction.
Select options
This product has multiple variants. The options may be chosen on the product page
E FIRE USA Home Kit (Brackets Included)
E FIRE USA Bundle (Brackets Included)
CT-492 IGNITER EROSION GAUGE (FORMERLY CT-468)
